Our mouse Chapsyn-110/PSD-93 FL490 conjugate monoclonal antibody from NeuroMab is produced in-house from clone N18/30. It detects human, mouse, rabbit, and rat Chapsyn-110/PSD-93 and is purified by Protein A chromatography. KO validated. Works in IHC, ICC.
PSD-93/Chapsyn-110 (also known as Channel-associated protein of synapse-110, Postsynaptic density protein PSD-93, Disks large homolog 2 and Dlg2) is a member of the membrane-associated guanylate kinase (MAGUK) family. The protein contains a guanylate kinase-like domain, 3 PDZ domains and 1 SH3 domain. Chapsyn110 binds to NMDA receptor subunits and Shaker K+ channel subunits to aid in forming a multiprotein scaffold which clusters receptors, ion channels, cytoskeletal protiens and other cell signaling proteins. In this manner, it plays a key role in postsynaptic targeting. It is found in brain in neuronal cells and located at the cell synapse, postsynaptic cell membrane and postsynaptic density. Chapsyn110 has been implicated in chronic pain, bilateral retinoblastoma and schizophrenia.
Purified by Protein A chromatography
Lot dependent: provided at 0.3-0.5 mg/mL
Monoclonal
N18/30
IgG1
ICC, IHC
Mouse
Dlg2 Dlgh2
110 kDa
Fusion protein amino acids 1-852 of rat Chapsyn-110 (accession number Q63622) produced recombinantly in E. Coli
Rat
Human, Mouse, Rabbit, Rat
AB_2939248
Aliquot and store at ≤ -20°C for long term storage. For short term storage, store at 2-8°C. For maximum recovery of product, centrifuge the vial prior to removing the cap.
Liquid
Produced by in vitro bioreactor culture of hybridoma line followed by Protein A affinity chromatography and conjugation of purified mAb. Purified mAbs are >90% specific antibody.
PBS with 0.09% azide
FL490 Ex: 491 nm, Em: 515 nm
No cross-reactivity against other MAGUK family members PSD-95, SAP97, SAP102 expressed in transfected cells
Each new lot of antibody is quality control tested by western blot on rat whole brain lysate and confirmed to stain the expected molecular weight band.
These antibodies are to be used as research laboratory reagents and are not for use as diagnostic or therapeutic reagents in humans.
United States
12 months from date of receipt
Disks large homolog 2 (Channel-associated protein of synapse-110) (Chapsyn-110) (Postsynaptic density protein PSD-93)
KO Validated
